- New improved design is smaller and lighter than the original Mini Mite
- Class V+ Chain is world's strongest and is exclusive to JET
- Allows use of smaller load chain without compromising safety
- Zinc coated load chain and coated brake hub minimize corrosion
- One simple lever changes direction and disengages gear train for fast chain adjustments
- New larger hooks with extra heavy duty latches
- Riveted rubber handle for comfort and safety
- Electrostatic powder painted before assembly to protect against rust
- Capacity unaffected at temperatures up to -40°C with suitable winter lubrication
- Tested to 150% of rated capacity
- Meets ANSI B30.21 specifications (Certificate included)
- Made in Japan
- Rated Lifting Capacity : 3 T
- Standard Lift : 10'
- Number of Falls : 1
- Load Chain Diameter : 9.0 mm
- Min. Distance Between Hooks : 16-3/16"
- Distance per Handle Pull : 1/2"
- Force Req. to Lift Capacity : 82 lb
- Lever Length : 14-1/8"
- A: 16-3/16"
- B: 7-11/32"
- C: 7-3/32"
- D: 3-1/4"
- E: 4-3/32"
- F: 6-5/8"
- G: 14-1/8"
- H: 1-13/32"
- J: 2-5/64"
Jet 110513 - (MM320-10) 3 Ton 10' Lift Mini-Mite II Lever Chain Hoist - Super Heavy Duty
